16 MX 900 Series Installation Guide
May 13, 2015
4. Attach the Contactless Module using the two screws.
5. Attach the ribbon cable from the Contactless Module to the MX 925
terminal.
Note: If more room is needed to attach the ribbon cable, temporarily
remove the top mounting plate.
Ribbon Cable
Mounting Plate
