24 MX 900 Series Installation Guide
May 13, 2015
I/O Modules with Port Names
Module 1 with Black Label, P/N P132-601-00-R
Module 2 with Red Label, P/N P132-602-00-R
Module 3 with Grey Label, P/N P132-603-00-R
Module 4 with Purple Label, P/N P132-604-00-R
USB COM 2 Ethernet Audio Berg Power
USB COM 2 COM 1 Ethernet USB Audio Power
USB COM 1 Ethernet Audio Power
