I/O Modules
The MX 900 Series terminals use one of six I/O Modules to make the following
connections. See the following section for I/O Module Illustrations.
Note: Use the Ethernet port on the I/O module only if the multiport cable is
not attached. Otherwise, use the Ethernet port on the multiport cable.
I/O Modules
Ter min al # De scr ipti on I/O Module P/N
MX 915
P/N M132-409-01-R
1 AUD, BERG ONLY, NO TAILGATE 132-601-00-R
2 PWR, AUD, BERG W/ TAILGATE,
ETH, USB OTG, COM 2
132-602-00-R
3 PWR, AUD, POE, USB OTG, USB
HOST, COM 1, COM 2
132-603-00-R
4 PWR, AUD, ETH, USB OTG, COM 1,
WIFI/BT
132-604-00-R
5 AUD, BERG W/ TAILGATE 132-605-00-R
6 PWR, ETH, USB HOST, USB DEVICE,
COM 2
132-606-00-R
MX 925
P/N M132-509-11-R
P/N M132-509-01-R
P/N M132-509-21-R
1 AUD, BERG ONLY, NO TAILGATE 132-601-00-R
2 PWR, AUD, BERG W/ TAILGATE,
ETH, USB OTG, COM 2
132-602-00-R
3 PWR, AUD, POE, USB OTG, USB
HOST, COM 1, COM 2
132-603-00-R
4 PWR, AUD, ETH, USB OTG, COM 1,
WIFI/BT
132-604-00-R
5 AUD, BERG W/ TAILGATE 132-605-00-R
6 PWR, ETH, USB HOST, USB DEVICE,
COM 2
132-606-00-R
