32
© VeriFone, Inc. All rights reserved.
Installation Guide P400/P400 Plus
Mounting P400 to a Flat Surface (Without a Mounting Plate)
To mount the terminal to a flat surface:
1 Align the terminal's footers to the holes on the mounting plate.
2 Fit the footers of the terminal into the footer holes.
3 Screw the mounting plate in place.
Mounting P400 with Mounting Plate to a Vertical Bracket
To mount the terminal with a mounting plate to a vertical bracket:
1 Ensure the mounting plate is attached to the terminal.
2 Align the three screw holes of the mounting plate with the vertical bracket
holes.
3 Screw the vertical bracket in place.
Mounting Considerations
Avoid having metallic objects in proximity to the contactless antenna. If you
need to mount the terminal to vertical or inclined surfaces, use a flat
mounting plate.
Periodic
Inspection
Periodically inspect the terminal for possible tampering. Signs of tampering
may include:
• Wires protruding from the device.
• Foreign objects inserted into the smart card or mag stripe slot.
• Signs of damage to the tamper-evident label.
• Warning message on the device display.
Customized plates must have four recessed areas big enough to fit the footers of
the terminal. This ensures that there is no gap between the terminal and the
mounting plate.
An enclosed metal frame or mount may negatively affect CTLS performance.
Un cadre ou un support métallique fermé peut affecter négativement les
performances du CTLS.
