VeriFone V200c Installation Guide

SETUP
Using the Magnetic Card Reader
V200
C AND V400C INSTALLATION GUIDE 31
Using the
Magnetic Card
Reader
V200c and V400c terminals support credit or debit card transactions via the
magnetic card reader.
To conduct a credit or debit card transaction:
1 Position the card with the magnetic stripe oriented downward, facing the
keypad.
2 To ensure a proper read of the magnetic stripe, swipe the card smoothly
through the reader in one direction (either towards the top of the screen or the
bottom of the keyboard), as shown in Figure 22.
Figure 22 Using the Magnetic Card Reader
3 Check the screen for confirmation of a successful transaction.
NOTE
V200c and V400c terminals use the same magnetic card reader.
Figure 22 shows a V400c example, but the same process works for V200c
terminals.

VeriFone V200c Specifications

General

Memory	64MB SDRAM
Touchscreen	Capacitive
Connectivity	Ethernet, RS-232, USB
Operating System	Verix
Card Readers	Triple track MSR, EMV smart card reader, Contactless NFC
Power Supply	AC input 100-240V, DC output 5V
Operating Temperature	0°C to 40°C
Certifications	EMV Level 1 and 2, PCI
