VeriFone V200c Installation Guide

SPECIFICATIONS
Technical Specifications
34 V200C AND V400C INSTALLATION GUIDE
SAM Requirements • 2 SAM slots
• ID-000 format
Communication • Ethernet
• Speed 10 Base-T /100 Base-TX
• Compliant with IEEE802.3 LAN networks
• Dial modem
• V.92 standard supported, line speeds from 2400 Kbps to 56 Kbps
• USB
• USB 2.0 high speed
• Supports 5 V / 600 mA to external USB device
• Multi-Communication port
• Supports the optional MOD 10 RS-232 + USB/Mini-USB Multi-
Communication dongle
Display • V200c terminals have a 2.8-inch portrait mode transmissive TFT LCD (QVGA,
240 x 320)
• V400c terminals have a 3.5-inch portrait mode capacitive color touchscreen
LCD (HVGA, 320 x 480)
• Software controllable back-light
Thermal Printer • Support 30 LPS for first 30 sec, and then printing speed will slow down to
meet 18 W power budget
• Supports 57 mm wide x up to 40 mm diameter paper roll
• Out-of-Paper Sensor
MOD 10 RS-232 +
USB/Mini-USB Multi-
Communication
Dongle
• Customized extension cable providing USB host port or USB client
functionality. Integrates RS-232, USB2.0 Host / Device IO ports into a 10-pin
RJ45 connector. The MOD 10 RS-232 + USB/Mini-USB Multi-Communication
dongle is not a standard in-box accessory.
V200c Plus and
V400c Plus
Additional Features
• SD Memory
• Bluetooth
• Wi-Fi

VeriFone V200c Specifications

General

Memory	64MB SDRAM
Touchscreen	Capacitive
Connectivity	Ethernet, RS-232, USB
Operating System	Verix
Card Readers	Triple track MSR, EMV smart card reader, Contactless NFC
Power Supply	AC input 100-240V, DC output 5V
Operating Temperature	0°C to 40°C
Certifications	EMV Level 1 and 2, PCI
