VeriFone VX 520 User Manual

4
F1 Button
Displays the next transaction when a list
is available, used in the ‘correction’ and
‘authorisation’ completion flow
F4 Button
Menu
Magnetic Swipe Card Slot
The magnetic strip must face inwards
towards the terminal
Enter
Press enter to confirm a setting or
accept an amount or other entries
Chip Reader
Firmly insert the card chip facing upwards, chip first
Clear
Back space or delete entered values
Cancel
Exit screen and display the application version number
1
VX 520 Device Description

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
