VeriFone VX 520 User Manual

6
Chip Reader
Thermal printer and paper roll
Screen
Contactless reader for Tap to Pay™ cards
Magnetic Swipe Card Slot
The magnetic strip must face inwards towards
the terminal
Enter
Press enter to confirm a setting or accept an
amount or other entries
Firmly insert the card chip facing upwards,
chip first
Clear
Back space or delete entered values
Cancel
Exit screen and display the application version number
2
VX 675 Device Description
TO INSERT A PAPER ROLL
Single layer thermal
57x30mm

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
