VX820 technical specifications
Processor 400 MHz, ARM11 32-bit RISC
processor
Security SSL v.3.0, 3DES encryption,
Master/Session and DUKPT key
management;
VeriShield file authentication;
PCI PTS 3.X approved
Memory 160 MB (128 MB of Flash, 32 MB of
SDRAM) standard,
designed to support up to 500 MB
optional
micro SD flash memory card
Physical Length: 173 mm (6.81 in.);
width: 87 mm (3.43 in.);
height: 35 mm (1.38in.);
weight: terminal 308 g (0.68 lbs.)
Display 240x320 pixel color TFT (QVGA),
supports up to 26 lines x 26
characters
Environmental 0° to 50° C (32° to 122° F)
operating temperature;
5% to 90% relative humidity, non-
condensing
Magnetic
card reader
Triple track (tracks 1, 2, 3), high
coercivity, bi-directional
Voltage AC input 100 - 240 V AC, 50/60 Hz;
DC output 8.6 - 9.4 V DC, 4.0 Amp
Primary
smart card
ISO 7816, 1.8 V, 3 V, 5 V; synchronous
and asynchronous cards;
EMV level 1 and 2 t ype approved
Contactless
applications
MasterCard PayPass M/Chip,
MasterCard PayPass MagStripe,
Visa payWave MSD, Visa payWave
qVSDC, Discover Zip,
American Express ExpressPay,
Pass-through access to ISO
14443-4 and MiFare card, for
direct host terminal based
application access, Secure
SoftSAM, Hardware
SAM card
reader
3 Security Access Modules (SAMs) SAM optional NFC applications, support for ISO
18092
Peripheral
ports
USB host and RS-232 to support
peripheral devices Telco
and Ethernet ports to support
communications
Printer Integrated thermal printer with
graphics capabilities,
18 lines per second, 24 or 32 columns,
standard paper roll 58 mm (2.25 in.) x
25M, single ply
