Embroidery Preparation
EN
Preparation for embroidery
Turn the power switch to off ("O"). Raise the
presser foot lifter.
Loosen the screw counter-clockwise to
remove the presser foot holder.
①
Screw
②
Presser foot holder
Turn the handwheel toward you to raise the
needle then loosen the needle clamp screw to
remove the needle.
①
Needle clamp screw
Remove the screws on the needle plate then
remove the needle plate.
Change the straight stitch plate and tighten
the screws.
①
Screws
Inserting a 75/11 needle, keep the at side of
the shaft to the back.
Please refer to page "Matching needle/fabric/
thread"
and
"Replacing the needle" for more
information.
①
Flat side of the shaft
②
Pin
2
1
1
2
1
1
1
1
1
