Table 2-1
5220 factory default port configuration
Optimized duplication and
replication
SAN Client FTMSHBA
configuration
Not applicableNot applicable5220 A
Slot 3, Port 1 - initiator
Slot 3, Port 2 - target
Not applicable5220 B
Slot 3, Port 1 - initiator
Slot 3, Port 2 - target
Not applicable5220 C
Slot 3, Port 1 - initiator
Slot 3, Port 2 - target
Slots 2 and 4, Port 1 - target5220 D
Slot 3, Port 1 - initiator
Slot 3, Port 2 - target
Slots 2 and 4, Port 1 - target5220 E
Table 2-2 describes the factory default target port configuration for a 5230 appliance.
Table 2-2
5230 factory default port configuration
Optimized duplication and
replication
FTMSHBA
configuration
Not applicableNot applicable5230 A
Slot 4, Port 1 - initiator
Slot 4, Port 2 - target
Not applicable5230 B
Slot 4, Port 1 - initiator
Slot 4, Port 2 - target
Not applicable5230 C
Slots 2 and 4, Port 1 - initiator
Slots 2 and 4, Port 2 - target
Slots 5 and 6, Port 1 - target5230 D
Slots 2 and 4, Port 1 - initiator
Slots 2 and 4, Port 2 - target
Slots 5 and 6, Port 1 - target5230 E
Table 2-3 describes the factory default target port configuration for a 5240 appliance.
34About the HBA port mode configuration
About FTMS reserved HBA ports and the factory default port mode configuration
