Versitron SG71090 - Page 13

www.versitron.com -13- SG71090
QoS function Ethernet type, IP-based, DSCP, TOS-based, VID-based, VLAN Tag-based packet
classification
Port rate control, storm control
Port Mirroring Mirror received frames to a sniffer port
AC Power Input (SG71090)
Interface IEC320 receptacle
Operating Input Voltages 100 ~ 240VAC, 50/60Hz, 1.7A
Power Consumption 40W max.
DC Power Input (sg71090-DC
Interfaces Screw-type terminal block
Operating Input Voltages +40 ~ +72VDC
Power Consumption 40W max.
DC Power Output
Operating Output Voltage +5VDC, 13A
Mechanical
Dimension (base) 17.44 x 9.65 x 1.69 Inches (W x D x H) (443 x 245 x 43 mm)
Housing Enclosed metal
Mounting Desktop mounting, 19” rack mounting
Environmental
Operating Temperature Typical -5
o
C ~ +50
o
C
Storage Temperature -25
o
C ~ +85
o
C
Relative Humidity 10% ~ 90% non-condensing
Electrical Approvals
FCC Part 15 rule Class A
CE EMC, CISPR22 Class A
Safety LVD, IEC60950-1
