2.7 Applying DC Power – SG71090-DC
The SG71090-DC power connector is shown below:
DC power input specifications
Receptacle: Screw-type terminal block
Operating Voltages: +40 ~ +72VDC
Power Consumption: 40W max.
Contacts
VDC+ input
VDC- input
Ground
SG71090-DC Power Connector
