3. Push the module into the slot until it is seated securely in the slot and then place the bail in lock position.
Connecting Fiber Cables
LC connectors are commonly equipped on most SFP. Identify the TX and RX connector before making the
cable connection. Plug in the cables as shown below. Make sure the RX-to-TX connection rule is followed
between two ends of the connected cable.
2.11 Making Fixed Duplex Fiber Connections
The following figure illustrates an example of a fixed duplex fiber port with duplex SC connectors:
A module with fixed duplex ST connectors is also available.
