www.versitron.com -25- SG71090
2.13 LED Indications
LED Function Color State Interpretation
POWER Power status Green ON The power is supplied to the switch.
OFF The power is not supplied to the switch.
Mngt Management status Green OFF The switch is in initialization and diagnostics.
BLINK The switch is initialized completely with diagnostic error.
ON The switch is initialized completely and normal.
1000M Port speed status Green ON 1000Mbps is selected
OFF 100Mbps or 10Mbps is selected.
Link/Act. Port link status Green ON Port link is established. (No traffic)
BLINK Port link is up and there is traffic.
OFF Port link is down.
