H-17

Parts List

RF Unit

PCB with Components CB1908001 POW:50 1-

CB1908002 POW:25 8-

Printed Circuit Board FR007990D 1-

FR007990E 2-

FR007990F 3-

FR007990G 6-

C 1001 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 1- B a3

C 1002 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A I1

C 1003 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A F3

C 1005 CHIP CAP. 12pF 500V CH CF316CH120J500AT K22271256 1- A I1

C 1006 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C4

C 1007 AL.ELECTRO.CAP. 2200uF 25V RE3-25V222M K40149055 6- B h2

C 1008 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A E3

C 1009 AL.ELECTRO.CAP. 100uF 25V ECEV1EA101UP K48140013 1- B i2

C 1010 CHIP CAP. 7pF 500V CH CF316CH070D500AT K22271252 1- B b1

C 1011 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B a3

C 1012 AL.ELECTRO.CAP. 10uF 25V MVA-25VC10MD55 K48140014 1- A C4

C 1013 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C2

C 1014 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C2

C 1015 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A C5

C 1016 AL.ELECTRO.CAP. 10uF 25V MVA-25VC10MD55 K48140014 1- A B4

C 1017 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B i3

C 1018 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- A J4

C 1019 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1-7 B b2

C 1019 CHIP CAP. 33pF 500V CH CF316CH330J500AT K22271261 25W 8- B b2

C 1019 FILM CAP. 33pF 500V UC232H0330J-T K33279024 50W 8- B b2

C 1020 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C2

C 1021 CHIP CAP. 6pF 500V CH GRM42-6CH060D500PT K22271209 1- B b2

C 1022 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C4

C 1023 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1-7 B b2

C 1023 CHIP CAP. 33pF 500V CH CF316CH330J500AT K22271261 25W 8- B b2

C 1023 FILM CAP. 33pF 500V UC232H0330J-T K33279024 50W 8- B b2

C 1024 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C4

C 1026 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C4

C 1027 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I5

C 1028 CHIP CAP. 22pF 500V CH CF316CH220J500AT K22271259 1- B b2

C 1029 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C4

C 1030 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A I5

C 1031 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B3

C 1032 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C5

C 1033 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B j4

C 1034 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- A I5

C 1035 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A G3

C 1036 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G3

C 1037 CHIP CAP. 18pF 500V CH CF316CH180J500AT K22271258 1- B b3

C 1038 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- A I5

C 1040 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G3

C 1042 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A D6

C 1043 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I5

C 1044 CHIP CAP. 18pF 500V CH CF316CH180J500AT K22271258 1- B b3

C 1045 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- A I5

C 1046 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A G3

C 1048 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b3

C 1049 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C6

C 1050 CHIP CAP. 0.0018uF 50V B GRM36B182K50PT K22178812 1- A C6

C 1052 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3

C 1053 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3

C 1054 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H4

C 1055 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A G4

C 1056 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6

C 1057 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A H4

C 1058 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- A H4

C 1059 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A H3

C 1060 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A G3

C 1062 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A H3

C 1064 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3

C 1065 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c4

C 1066 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6

C 1068 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5

C 1069 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6

C 1070 CHIP CAP. 0.0022uF 50V B GRM36B222K50PT K22178813 1- B f6

C 1071 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5

C 1072 CHIP CAP. 1uF 10V B GRM40B105K10PT(0.85) K22100803 1- B h4

C 1073 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C5

C 1074 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

Brand	Vertex Standard
Model	VX-4200 Series
Category	Transceiver
Language	English

Vertex Standard VX-4200 Series Service Manual
