Vertex Standard VX-4200 Series Service Manual

I-5
Parts List
FRONT-C Unit (VX-4100)
PCB with Components CB2527001
Printed Circuit Board AAD24X000 FR010720B 1-
FR010720G 6-
C 4001 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B f2
C 4002 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f2
C 4003 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f3
C 4004 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 4005 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 4006 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 4007 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g3
C 4008 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 4009 CHIP TA.CAP. 4.7uF 25V TEMSVB21E475M-8R K78140019 1- B e1
C 4010 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- B e1
C 4011 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B f1
C 4012 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e1
C 4013 CHIP TA.CAP. 4.7uF 25V TEMSVB21E475M-8R K78140019 1- B d2
C 4014 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B d2
C 4015 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B c2
C 4016 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- B c2
C 4017 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c2
C 4018 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1-5 B g2
D 4001 DIODE 1SS400 TE61 G2070634 1- B g2
D 4002 LED BRPG1211C-TR G2070654 1- A C1
D 4003 DIODE DA221 TL G2070178 1- B e2
D 4003 DIODE EDZ TE61 5.1B G2070998 13- B e2
D 4004 DIODE DA221 TL G2070178 1- B e2
D 4004 DIODE EDZ TE61 5.1B G2070998 13- B e2
D 4005 DIODE DA221 TL G2070178 1- B e2
D 4005 DIODE EDZ TE61 5.1B G2070998 13- B e2
D 4006 DIODE DA221 TL G2070178 1- B e2
D 4007 LED TLGU1008A(TAPE) G2070956 1- A D1
D 4008 LED TLGU1008A(TAPE) G2070956 1- A D1
D 4009 LED TLGU1008A(TAPE) G2070956 1- A F1
D 4010 LED TLGU1008A(TAPE) G2070956 1- A E1
D 4011 LED TLGU1008A(TAPE) G2070956 1- A E1
D 4012 LED TLGU1008A(TAPE) G2070956 1- A F1
D 4013 LED TLOU1008A(TAPE) G2070958 1- A C3
D 4013 LED TLOU1020(T14) G2070990 10- A C3
D 4014 LED TLOU1008A(TAPE) G2070958 1- A E3
D 4014 LED TLOU1020(T14) G2070990 10- A E3
D 4015 LED TLOU1008A(TAPE) G2070958 1- A F3
D 4015 LED TLOU1020(T14) G2070990 10- A F3
J 4001 CONNECTOR R41-2509H P1090714 1- A A2
J 4002 CONNECTOR 18FLT-SM1-TB P1091176 1- B e2
JP4001 WIRE ASSY BRN 35 (2)/(2) T51103502 1-5
MC4001 MIC. ELEMENT EM-140 M3290032 1- A B3
Q 4001 TRANSISTOR DTC144EE TL G3070075 1- B d1
Q 4002 IC TC4S66F TE85R G1090893 1- B f2
Q 4003 TRANSISTOR DTC144EE TL G3070075 1- B d2
Q 4004 IC BU4094BCFV-E2 G1093527 1- B c1
Q 4004 IC CD4094BPWR G1093866 6- B c1
Q 4005 TRANSISTOR DTC144EE TL G3070075 1- B d1
Q 4006 TRANSISTOR DTC144EE TL G3070075 1- B d1
Q 4007 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 4008 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 4009 IC M5278L09M 600C G1093102 1- B e1
Q 4010 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 4011 TRANSISTOR DTC144EE TL G3070075 1- B c2
Q 4012 IC M5278L05M 600C G1093101 1- B c2
Q 4013 TRANSISTOR DTC144EE TL G3070075 1- B b2
Q 4014 TRANSISTOR DTC144EE TL G3070075 1- B b2
R 4001 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f3
R 4002 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B f2
R 4003 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g3
R 4004 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 4005 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 4006 CHIP RES. 820 1/10W 5% RMC1/10T 821J J24205821 1- B d1
R 4007 CHIP RES. 220 1/10W 5% RMC1/10T 221J J24205221 1- B d1
R 4007 CHIP RES. 470 1/10W 5% RMC1/10T 471J J24205471 6- B d1
R 4008 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 4009 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 4010 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B c2
R 4011 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B c2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
