J-5
Parts List
FRONT-D Unit (VX-4200)
PCB with Components CB2528001
Printed Circuit Board AAD25X000 FR010280C 1-
FR010280I 6-
C 5001 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 5002 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g3
C 5003 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 5004 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g2
C 5005 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B f2
C 5006 CHIP TA.CAP. 4.7uF 25V TEMSVB21E475M-8R K78140019 1- B c2
C 5007 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B c2
C 5008 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- B b2
C 5009 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B b2
C 5010 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- B e1
C 5011 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e2
C 5012 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e2
C 5013 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e2
C 5014 CHIP TA.CAP. 4.7uF 25V TEMSVB21E475M-8R K78140019 1- B f1
C 5015 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e2
C 5016 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B f2
C 5017 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B f1
C 5018 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- B f1
C 5019 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B f1
C 5020 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B f1
C 5021 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B f3
C 5022 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f3
C 5023 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f3
C 5024 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 6- B e1
C 5025 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1-5 B g2
D 5001 LED BRPG1211C-TR G2070654 1- A G2
D 5002 DIODE 1SS400 TE61 G2070634 1- B g2
D 5003 LED TLOU1008A(TAPE) G2070958 1- A B2
D 5003 LED TLOU1020(T14) G2070990 10- A B2
D 5004 LED TLOU1008A(TAPE) G2070958 1- A B1
D 5004 LED TLOU1020(T14) G2070990 10- A B1
D 5005 LED TLOU1008A(TAPE) G2070958 1- A B1
D 5005 LED TLOU1020(T14) G2070990 10- A B1
D 5006 LED TLOU1008A(TAPE) G2070958 1- A C3
D 5006 LED TLOU1020(T14) G2070990 10- A C3
D 5007 LED TLOU1008A(TAPE) G2070958 1- A D3
D 5007 LED TLOU1020(T14) G2070990 10- A D3
D 5008 LED TLOU1008A(TAPE) G2070958 1- A E3
D 5008 LED TLOU1020(T14) G2070990 10- A E3
D 5009 DIODE DA221 TL G2070178 1- B f3
D 5009 DIODE DA204U T106 G2070242 6- B f3
D 5010 LED TLOU1008A(TAPE) G2070958 1- A F3
D 5010 LED TLOU1020(T14) G2070990 10- A F3
D 5011 LED TLOU1008A(TAPE) G2070958 1- A F3
D 5011 LED TLOU1020(T14) G2070990 10- A F3
D 5012 LED TLOU1008A(TAPE) G2070958 1- A G2
D 5012 LED TLOU1020(T14) G2070990 10- A G2
D 5013 DIODE 1SS400 TE61 G2070634 1- B e1
D 5014 DIODE DA221 TL G2070178 1- B g2
D 5015 DIODE 1SS400 TE61 G2070634 1- B e1
D 5016 DIODE DA221 TL G2070178 1- B e2
D 5016 DIODE DA204U T106 G2070242 6- B e2
D 5017 DIODE DA221 TL G2070178 1- B e3
D 5018 DIODE 1SS400 TE61 G2070634 1- B f1
D 5019 LED TLOU1008A(TAPE) G2070958 6- A G1
D 5019 LED TLOU1020(T14) G2070990 10- A G1
D 5020 DIODE UDZS TE-17 4.3B G2070874 6- B a1
DS5001 LCD 064250 G6090153 1- A D1
J 5001 CONNECTOR R41-2509H P1090714 1- A A2
J 5002 CONNECTOR 18FLT-SM1-TB P1091176 1- B e2
JP5001 WIRE ASSY BRN 35 (2)/(2) T51103502 1-5
MC5001 MIC. ELEMENT EM-140 M3290032 1- A B3
Q 5001 TRANSISTOR DTC144EE TL G3070075 1- B a2
Q 5002 TRANSISTOR XP1501-(TX) G3070143 1- B c2
Q 5003 TRANSISTOR CPH6102-TL G3070223 1- B c2
Q 5004 TRANSISTOR DTC144EE TL G3070075 1- B a2
Q 5005 TRANSISTOR XP1501-(TX) G3070143 1- B f1
Q 5006 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- B f1
Q 5007 IC M5278L09M 600C G1093102 1- B c2
Q 5008 IC NJU6624AFG1-03 G1093881 1- B d1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
