Vertex Standard VX-4200 Series Service Manual

J-6
FRONT-D Unit (VX-4200)
Parts List
Q 5009 IC M5278L05M 600C G1093101 1- B f1
Q 5010 IC TC4S66F TE85R G1090893 1- B f2
R 5001 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B c3
R 5002 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- B a2
R 5003 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B c2
R 5004 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- B a2
R 5004 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 6- B a2
R 5005 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g3
R 5006 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B d2
R 5007 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B c2
R 5008 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 5009 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 5010 CHIP RES. 270 1/10W 5% RMC1/10T 271J J24205271 1- B f1
R 5012 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 5013 CHIP RES. 270 1/10W 5% RMC1/10T 271J J24205271 1- B d3
R 5013 CHIP RES. 560 1/10W 5% RMC1/10T 561J J24205561 6- B d3
R 5014 CHIP RES. 270 1/10W 5% RMC1/10T 271J J24205271 1- B a1
R 5014 CHIP RES. 560 1/10W 5% RMC1/10T 561J J24205561 6- B a1
R 5015 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B g2
R 5016 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B g2
R 5017 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B g2
R 5017 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 6- B g2
R 5018 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B f1
R 5019 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f2
R 5020 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- B f1
R 5021 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B f1
R 5022 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- B f2
R 5023 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B f2
R 5024 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- B f1
R 5027 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B g2
R 5028 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B e1
R 5030 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f3
R 5031 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B f2
R 5032 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e3
R 5033 CHIP RES. 470 1/10W 5% RMC1/10T 471J J24205471 6- B a1
TH5001 THERMISTOR ERTJ1VV473J G9090122 1- B f2
VR5001 POT. RK09L1140 20KA J60800265 1- A A1
LCD HOLDER RA0487400 1-
LIGHT GUIDE (LCD) RA0487500 1-
REFLECTOR SHEET RA0487600 1-
DIFFUSER SHEET RA0487700 1-
INTER CONNECTOR RA0487800 1
INTER CONNECTOR RA048780A 2-
SPONGE RUBBER (WND) RA0487900 1-
LIGHT GUIDE RA0514300 1-
