P-3

RELAY Unit (Option)

Parts List

VXR-9000 UHF Service Manual

PCB with Components CS2382101

C 8001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 8002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C2

C 8003 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3

C 8004 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A B1

C 8004 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A B1

C 8005 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A C2

C 8005 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A C2

C 8006 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A C3

C 8006 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A C3

C 8007 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8008 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8009 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8010 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8011 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8014 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8015 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8016 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8017 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A B1

C 8018 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A C2

C 8019 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A C3

C 8020 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A B2

C 8021 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A B3

C 8021 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A B3

C 8022 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8023 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8024 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8025 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8026 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8027 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8028 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8029 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8030 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3

C 8031 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G3

C 8032 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G3

C 8033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G3

C 8034 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G3

C 8035 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G3

C 8036 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G3

C 8037 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G3

C 8038 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G2

C 8039 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G2

C 8040 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A G3

C 8041 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A G3

C 8041 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A G3

C 8042 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A H1

C 8043 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A G1

C 8044 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A H2

C 8044 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A H2

C 8045 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A H2

C 8045 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A H2

C 8046 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A H1

C 8046 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A H1

C 8047 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A G1

C 8047 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A G1

C 8048 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A H2

C 8049 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A H2

C 8050 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A H1

C 8051 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G1

C 8052 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A H2

C 8053 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A H2

C 8053 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A H2

C 8054 CHIP TA.CAP. 10uF 25V TEESVC1E106M12R K78140021 1- A G3

C 8055 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A H3

C 8056 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1-6 A H3

C 8056 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 7- A H3

C 8057 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A H3

C 8058 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B1

D 8001 DIODE DSA3A1 G2090445 1- A A3

D 8002 DIODE C30T04QH-TE24L G2070896 1- A D2

D 8003 DIODE C30T04QH-TE24L G2070896 1- A D3

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
