Vertex Standard VXR-9000 Service Manual

P-4
RELAY Unit (Option)
Parts List
VXR-9000 UHF Service Manual
D 8004 DIODE BAS316 G2070716 1- A B1
D 8005 DIODE BAS316 G2070716 1- A B2
D 8006 DIODE HZM9.1NB3 TR-E G2070404 1- A B2
D 8007 DIODE 1SS355 TE-17 G2070470 1- A G3
D 8008 DIODE 1SS355 TE-17 G2070470 1- A G3
D 8009 DIODE 1SS355 TE-17 G2070470 1- A G3
D 8010 DIODE 1SS355 TE-17 G2070470 1- A G3
D 8011 DIODE 1SS355 TE-17 G2070470 1- A H2
D 8012 DIODE 1SS355 TE-17 G2070470 1- A H2
D 8013 LED SML-210VTT86 G2070768 1- A E3
D 8014 DIODE BAS316 G2070716 1- A F2
D 8015 DIODE UDZS TE-17 5.6B G2070910 1- A G2
F 8001 CHIP FUSE 1A R429 001 Q0000089 1-9 A A3
F 8001 CHIP FUSE 1A 0466001.NR Q0000171 10- A A3
F 8002 CHIP FUSE 15A 451 015.MR 15A Q0000105 1- A F3
J 8001 TERMINAL Y106 S5000179 1- A A2
J 8002 TERMINAL Y106 S5000179 1- A C2
J 8003 TERMINAL Y106 S5000179 1- A C3
J 8004 CONNECTOR IL-Y-11P-S15T2-E P0090653 1- A F3
J 8005 CONNECTOR IL-Y-11P-S15T2-E P0090653 1- A F3
J 8006 CONNECTOR IL-Y-6P-S15T2-EF P0091028 1- A G3
J 8007 CONNECTOR IL-Y-3P-S15T2-EF P0090644 1- A H2
J 8008 CONNECTOR B2B-EH(LF)(SN) P0090666 1- A G1
J 8009 CONNECTOR B2B-EH(LF)(SN) P0090666 1- A G1
J 8010 CONNECTOR IL-Y-3P-S15T2-EF P0090644 1- A H3
Q 8001 TRANSISTOR DTC144EE TL G3070075 1- A D2
Q 8002 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- A B3
Q 8003 IC LM2902PWR G1094009 1- A G3
Q 8004 TRANSISTOR DTC144EE TL G3070075 1- A G2
Q 8005 TRANSISTOR FMG2 T148 G3070015 1- A H2
Q 8006 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- A H3
Q 8007 TRANSISTOR 2SB1201S-TL G3070195 1- A F2
Q 8008 TRANSISTOR DTC144EE TL G3070075 1- A G2
R 8001 CEMENT RES. 5.6 5W 10% ERF-5AK5R6 J30376569 1-7 A C3
R 8001 CEMENT RES. 5.6 5W 5% BWR5C5R6J J30375569 8- A C3
R 8003 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A B2
R 8004 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A B2
R 8005 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A B3
R 8006 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 8007 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A B3
R 8008 CHIP RES. 18k 1/16W 1% RMC1/16 183FTP J24183183 1- A G2
R 8009 CHIP RES. 100k 1/16W 1% RMC1/16 104FTP J24183104 1- A G2
R 8010 CHIP RES. 18k 1/16W 1% RMC1/16 183FTP J24183183 1- A G2
R 8011 CHIP RES. 100k 1/16W 1% RMC1/16 104FTP J24183104 1- A G2
R 8012 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G2
R 8013 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A G2
R 8014 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G2
R 8015 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A G2
R 8016 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G2
R 8017 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G3
R 8018 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A H2
R 8019 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G3
R 8020 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G3
R 8021 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G2
R 8022 CHIP RES. 18 1/2W 5% RMC1/2 180JTE J24275180 1- A G2
R 8023 CHIP RES. 18 1/2W 5% RMC1/2 180JTE J24275180 1- A G2
R 8024 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A G2
R 8025 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- A G2
R 8026 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A H2
R 8027 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A H2
R 8028 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A H2
R 8029 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A H2
R 8030 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A E3
R 8031 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A G3
R 8032 CHIP RES. 1k 1/4W 5% RMC1/4 102JATP J24245102 1- A G2
RL8001 RELAY DC12V ACP131 DC12V M1190152 1- A C2
RL8002 RELAY DC12V ACP131 DC12V M1190152 1- A C3
S 8001 SLIDE SWITCH SSSS912N-2A-OR N6090094 1- A A1
TP8001 TERMINAL TP-K IPS-1136 Q5000050 1- A G3
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
