Vertex SR Series User Manual

- 16 -
CHAPTER 3: Advanced Features
Light Manager (Main Menu 1)
The Light Manager is the main interface from which you will program your Vertex Illumina.
Withinit,youwillndthefollowingfunctions:
Functions
1-1 OFF: Select this function and hold the SELECT button to turn the unit off.
1-2 DEMO: Select this function and hold the SELECT button to begin a preprogrammed demo mode.
1-3 STANDARD: Make Moon Light selections here:
1-3-1 NO MOON: No Moon Light cycle.
1-3-2 MOON LIGHT: Standard Moon Light function. See Section 1-4-5-2 on the following page.
1-4 CUSTOM:ThisSubmenucontainsalloftheUsercongurablelightsettings:
1-4-1 LIGHT COMPOSER:Thisapplicationallowsyoutocreateandtestspeciclightoutputsand
uses the following interface:
Use the ◄/OK and ESC/► buttons to scroll between the channels. Use the + and – buttons to adjust the
values to the desired level. Press and hold ◄/OK to exit the Light Composer while retaining your color
composition (no lighting schedule). Press and hold ESC/► exit without saving any settings.
SELECT ▲ ▼ ESC
1-1 OFF ○
1-2 DEMO ○
1-3 DEFAULT ○
1-4 CUSTOM ○
◄/OK + – ESC/►
LIGHT COMPOSER
WHITE: 00-100%
ROYAL BLUE: 00-100%
BLUE: 00-100%
