FOREWORD
This manual is written to inform you, as a user, how to work safely with our product. The manual provides information
on the level of a technical specialist. The system should not be operated by unauthorized personnel or technical
specialist without training.
Read and fully understand these instructions before using the equipment. Make sure all security recommendations
and precautions have been read and understood. Also, read the security recommendations of complementary
supplier’s documents. The users remain responsible for supervision and compliance with this manual.
This manual only applies to the “V700 Series” modular carrier for various applications and does not describe the
complete “VertiDrive” set of equipment with applicable tools. Upon request, different tools for the V700 Series robot
are available, such as a safety winch system and specifically designed equipment. Contact the support department
of VertiDrive B.V. for more information.
As a manufacturer, we strongly recommend to:
 Contact VertiDrive B.V. for urgent questions;
 Keep the manual in a dry, safe, and available place for everyone who’s involved;
 Keep all security marks on the system visible, replace them if needed.
Equipment supplied by VertiDrive B.V., to which the machine directive is applicable, complies with the EU declaration
of conformity.
Contents of manual
This manual contains the following subjects:
 Product specification;
 Product certification;
 Safety information;
 System description;
 Installation instructions;
 Operation instructions;
 Maintenance instructions;
 Storage and transport instructions.
Notice
All applicable procedures, described in this manual, have been verified by VertiDrive B.V.
The provided images are meant to represent the actual product, but the image content may vary from reality.
