Electrical specifications
Input voltage range: 230V systems: 200-240 VAC, 120V systems: 100-120 VAC.
Input frequency range: 50/60 Hz.
Input current (without cooling): 230V systems: 5A, 120V systems: 10A.
Input current (with cooling): 230V systems: 7A, 120V systems: 14A.
Output voltage to the robot: 70 VDC (motors) and 24 VDC (logic).
Remote control system: Hetronic Nova XL.
Range remote control: 100 meters.
Environmental conditions
Working temperature (without cooling): -20 to +35°C (0 to +95°F).
Working temperature (with cooling): -20 to +50°C (0 to +120°F).
Storage temperature: -40 to +85°C (-40 to +185°F).
IP rating robot: IP65.
IP rating control box: IP66.
IP rating remote control: IP66.
Applications
The V700 Series robot can be equipped with different types of applications:
 Swing arm for abrasive blasting (313550);
 Swing arm for high-pressure washing (322006, 322032, 322033 & 322034);
 Swing arm for ultra-high-pressure water blasting (310143);
Contact VertiDrive for detailed information and advice on all available applications.
The procedures for installing and using the different applications are described in the application user manuals.
Documentation
V700 Series robot system (standard)
User Manual VertiDrive V700 Series robot (supplied with robot system).
Control system wiring diagram (supplied with control box).
322027 V700 Series Robot – IPM (Illustrated Parts Manual).
3.4 F-03 Startup Checklist.
3.4 F-04 Inspection and Maintenance Schedule.
V700 Series ancillary equipment (optional)
Optional: Transport frame - User Manual and IPM.
Optional: Swing arm abrasive blasting - User Manual and IPM.
Optional: HP washing arm - User Manual and IPM.
Optional: UHP hydro blasting arm - User Manual and IPM.
