 Rear magnet: clean, check for damages, check magnet height adjustment (full range). Use pressurized air
or low-pressure water jet to clean. If the dirt contains metal particles (e.g., residue from the surface cleaning)
it can be very hard to remove this contamination from the magnet surface. Use a brush or a damp cloth in
this case.
 Drive and swing arm motors: clean, check for damages of sleeve and electric cable, check integrity and
tightness of cable gland, check tightness of (6x) M6 mounting screws. Check for any abnormal sounds during
operation. The motors are completely sealed and supplied with lubricant for life. If inspection reveals any
issues with the motor, the complete unit must be replaced.
 Gearboxes: clean, check shaft on play (1-2° maximum), check for oil leakage, check for any abnormal
sounds during operation. Note that the gearboxes are supplied complete with lubricant for life and require
no regular maintenance. If inspection reveals any issues with the gearbox, the complete unit must be
replaced.
 Junction box and connectors: clean, check for damages, check integrity and tightness of all junction box
connections (e.g., corrosion, moisture, debris).
 Umbilical connector: clean, check for damages, check tightness of cable gland, check integrity and
functionality of locking levers. Replace the locking levers in case of any damage that hampers functionality.
 WCS sensor: clean, check for damages (sensor body and cable), check functionality. Green LED indicator
must turn on when powered, the orange LED indicator must turn on when a metal surface is detected.
 Swing arm limit switches: clean, check for damages (sensor body and cable), check functionality. Green
LED indicator must turn on when powered, the orange LED indicator must turn on when the swing arm tube
is placed directly over the sensor at maximum 6mm distance.
 Swing arm actuator: clean with compressed air and/or WD40 or similar, check for damages (actuator and
cable), move for full range up and down to check functionality. Check for any abnormal sounds during
operation. The actuator is completely sealed and supplied with lubricant for life. If inspection reveals any
issues with the actuator, the complete unit must be replaced.
CONTROL BOX:
 Cabinet: clean, check for damages, check integrity of all electrical connection at the bottom, check
antenna on damages, check integrity of the door seal.
 Remote control: clean, check for damage (casings, seals on switches, etc.), check integrity and functionality
of all controls on the remote, check integrity of both batteries.
 Cooling (optional): clean, inspect the cover and fan on the outside of the cabinet for dust and / or dirt build-
up, clean with pressurized air if needed. Check functionality of the cooling fans: set the thermostat located
on the inside of the cabinet door to 0°C and switch on mains power. Cooling fans must start moving, check
for any abnormal sounds. After the functional test is done, return the thermostat to 30°C setting.
UMBILICAL CABLE:
 Cable: unroll cable, clean, and check entire length of cable on damages
 Connectors: clean (with contact spray if needed), check for damages (casing and seals), check tightness
of cable gland, check integrity and functionality of locking levers. Replace the locking levers in case of any
damage that hampers functionality.
 Tension reliefs: clean, check for damages, check correct position of tension relief on umbilical cable, check
tightness of M6 screws.
(ULTRA) HIGH PRESSURE EQUIPMENT:
 Hoses: unroll hose, clean, and check entire length of hose on damages, replace immediately if damaged.
 Connectors: clean, check for damages (casing and seals), check if no water comes out of leakage holes if
pressure is applied.
 Ensure there are functional whip checks on all connections.
Check the applicable user manual(s) for inspection and maintenance instructions for the application and the
transport trolley / winch system if used.
