Vertiv CYBEX SC 840D User Manual

Figure 2.2 SC KM145 Switch
ITEM DESCRIPTION ITEM DESCRIPTION
1 LED DPP channel indicator 11 PC audio jack (3.5 mm stereo)
2 LED channel selector 12 PC keyboard/mouse USB Type-B port
3 Channel label 13 PC ports
4 PCport selectors 14 CONSOLEmouse PS/2 mini-DIN 6-pin port
5 DPP freeze button 15 CONSOLE keyboard PS/2 mini-DIN 6-pin port
6 Num lock indicator 16 CONSOLE keyboard/mouse USB Type-A port
7 Caps lock indicator 17 CONSOLE audio jack (3.5 mm stereo)
8 Scroll lock indicator 18 CONSOLE DPP LED connection indicator
9 AC power inlet 19 CONSOLE system reset
10 DPP USB Type-B port 20 CONSOLE DPP USB Type-A port
Table 2.2 SC KM145 Switch Description
2 Basic Operation
5

Vertiv CYBEX SC 840D Specifications

General

Brand	Vertiv
Model	CYBEX SC 840D
Category	Switch
Language	English
