Electrical Installation
Vertiv | Liebert CRD10 | User Manual 61
Table 4-4 Correspondence between unit CAN ID and DIP SW3 address
CAN ID
SW3-1
SW3-2
SW3-3
SW3-4
SW3-5
SW3-6
SW3-7
SW3-8
Comment
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Master Unit
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Slave Unit #1
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
Slave Unit #2
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
Slave Unit #3
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
Slave Unit #4
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
Slave Unit #5
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
Slave Unit #6
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
Slave Unit #7
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
Slave Unit #8
9
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
Slave Unit #9
10
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
Slave Unit #10
11
ON
ON
OFF
ON
OFF
OFF
OFF
OFF
Slave Unit #11
12
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
Slave Unit #12
13
ON
OFF
ON
ON
OFF
OFF
OFF
OFF
Slave Unit #13
14
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
Slave Unit #14
15
ON
ON
ON
ON
OFF
OFF
OFF
OFF
Slave Unit #15
NOTE: The PACC can connect up to 16 units, and the unit CAN ID address must be set in sequence from 0 to
15.
