8 VERTIV™ - Liebert
®
EFC - UM - 10040805MAN_ENG - 30.03.2023
70.0
2.76
70.0
2.76
90.0
3.54
90.0
3.54
DET. "A"
FIXING NUT
LIFTING BRACKET
PROTECTION GASKET
LIFTING TUBE
LIFTING TUBES OPTION
STRAIGHT SHACKLE SIZE 25 (1") (UNI 1947)
"A" TYPE (NOT SUPPLIED WITH LIFTING TUBES OPTION)
BASEMENT
BASEMENT
SPACE TO INSERT BELT OR CHORD

DET. "A"

Risk of heat exchanger damage due to
UV exposure: Before assembling the fan
module, and during all the transport and
storage operations, it is mandatory to keep
the composite heat exchanger protected
from direct and continuous solar radiation,
     󰀨  
exchanger material.
70.0
2.76
70.0
2.76
90.0
3.54
90.0
3.54
DET. "A"
FIXING NUT
LIFTING BRACKET
PROTECTION GASKET
LIFTING TUBE
LIFTING TUBES OPTION
STRAIGHT SHACKLE SIZE 25 (1") (UNI 1947)
"A" TYPE (NOT SUPPLIED WITH LIFTING TUBES OPTION)
BASEMENT
BASEMENT
SPACE TO INSERT BELT OR CHORD
