Vertiv Liebert EFC - Enclosure B - Dimensional Data;Connections

Enclosure B - Dimensional Data/Connections
B - 1 VERTIV™ - Liebert
®
EFC - UM - 10040805MAN_ENG - 30.03.2023
Liebert
®

3650.0 143.70
2062.5 81.20
172.5 6.79
3470.0 136.61
1117.0 43.98
3493.0 137.52
4587.0 180.59
1198.3 47.18
1700.0 66.93
165.0 6.50
2200.0 86.61
AIR OUT
135.0 5.31
860.0 33.86 2470.0 97.24
AIR OUT
140.0 5.51
DET. A
40.0 1.57
M8, TYP 26
DET. B
M8, TYP 26
2510 98.86
2500.0 98.43
216.7 8.53
40.0 1.57
3654.0 143.86
A
B
325.0 12.80
1850.0 72.83
AIR INLET
325.0 12.80
860.0 33.86 2472.0 97.32
AIR INLET
 Here shown the single unit left, on the single unit right the electrical panel is on the opposite side
