Vertiv Liebert EFC - Page 61

B - 2VERTIV™ - Liebert
®
EFC - UM - 10040805MAN_ENG - 30.03.2023
Enclosure B - Dimensional Data/Connections
Liebert
®

4500.0
177.17
2912.5 114.67
172.5 6.79
1415.0 55.71
3470.0 136.61
1117.0 43.98
3493.0 137.52
4587.0 180.59
120.0 4.72
2550.0 100.39
165.0 6.50
2600.0 102.36
AIR OUT
135.0 5.31
860.0 33.86
2470.0 97.24
AIR OUT
140.0 5.51
1117.0 43.98
325.0 12.80
2250.0 88.58
AIR IN
325.0 12.80
860.0 33.86
2472.0 97.32
AIR IN
139.5 5.49
1115.5 43.92
A
DET. A
40.0 1.57
40.0 1.57
M8, TYP 26
B
DET. B
40.0 1.57
40.0 1.57
M8, TYP 26
20.0 .79
20.0 .79
20.0 .79
20.0 .79
4504.0 177.32
116.0 4.57
2911.0 114.61
2900.0 114.17
382.0 15.04
TYP
440.0 17.32
TYP
359.0 14.13
TYP
359.0 14.13
TYP
 Here shown the single unit left, on the single unit right the electrical panel is on the opposite side
