Enclosure C - Refrigerant, Hydraulic and Electrical Connections
C - 2 VERTIV™ - Liebert
®
EFC - UM - 10040805MAN_ENG - 30.03.2023
3
6
10
15
16
FG
5
6
7
8
9
12
4
13 13
6
6
17
11
19
T
6
6
6
INSIDE PROCESS FAN MODULE
6
6
14
6
6
6
18
18
18
MC
2
1a
MC
2
1b
19
NTC TEMPERATURE SENSOR FOR
DIGITAL COMP.
18 ACCESS VALVE 1/4 SAE
17 HIGH PRESSURE TRASDUCER
16 LOW PRESSURE TRANSDUCER
EVAPORATOR
14 SHUT OFF SOLENOID VALVE
SHUT-OFF VALVE
12 CHECK VALVE
11 CHECK VALVE 10 bar
10 THERMOSTATIC EXPANSION VALVE
9 SIGHT GLASS
8 FILTER DRYER
7 SAFETY VALVE
6 ACCESS VALVE 5/16 SAE
LIQUID RECEIVER
4 AIR COOLED CONDENSER
HIGH PRESSURE SWITCH
2 CRANKCASE HEATER
1b SCROLL COMPRESSOR
1a DIGITAL SCROLL COMPRESSOR
