Enclosure C - Refrigerant, Hydraulic and Electrical Connections
C - 4 VERTIV™ - Liebert
®
EFC - UM - 10040805MAN_ENG - 30.03.2023

WATER INLET
NOT SUPPLIED
DRAIN PANEL DRAINAGE OUTLET /
BLEED OFF OUTLET
1
3
4
5
6
7
8
9
10
10
11
12
6
2
O
1.1/4"
O 3/4"
FZAL
14
INSIDE PROCESS FAN MODULE
OVERFLOW CIRCUIT OUTLET
OVERFLOW CIRCUIT OUTLET
OD 50 mm
OD 50 mm
15
OPTIONAL
RP 1.1/2"
PI
13
 
 UV LAMP (WHERE INSTALLED)
14 FLOW SWITCH
 MANOMETER
12 MOTORIZED BALL VALVE
11 PUMP
10 LEVEL SWITCH
9 CONDUCTIVIMETER
8 PRESSURE REGULATOR
 
7 FLOW METER
6 FILTER
 BALL VALVE
4 VALVE
 DRAIN PANEL
2 SPRINKLERS
1 PLATE HEAT EXCHANGER
