2.3 Front Panel and Controls
The Liebert GXT4 rack/tower models in various power ratings have the same general appearance,
controls and features as shown in the following figure. The various rack/tower and minitower models differ
largely in the type of receptacles each has.
Figure 2.1 Front view
NO. DESCRIPTION
1 Ventilation slots
2 Operation and displaypanel
2.4 Rear Panel Features
The rear panel of the Liebert® GXT4 has these features:
• Liebert® IntelliSlot™ Port
• USB port
• Input Circuit Breaker
• Input Receptacle
• General Output Receptacles
• Programmable Output Receptacles
• Cable Strain-relief Attachment Hole
• External Battery Connector
• Cooling Fan
• RS-232 port
• Terminal Block Communication
• Output Circuit Breakers (only on 3000VA models)
