208/230 - 1 Ph - 60Hz 277 - 1 Ph - 60Hz 208/230 - 3 Ph - 60Hz 460 - 3 Ph - 60Hz
Base Evaporator
Model Number
MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E
Condensing Unit
Model Number
MC*26W MC*38W MC*26W MC*38W MC*26W MC*38W MC*26W MC*38W
with Humidifier
FLA 27.6 32.7 22.5 26.4 — 23.2 — 11.9
WSA 30.6 37.0 25.1 30.0 — 26.2 — 13.5
OPD 40 50 35 40 — 35 — 15
with Electric Reheat and Humidifier
FLA 46.2 51.3 38.5 42.4 — 33.6 — 16.9
WSA 55.5 61.8 46.5 51.4 — 40.8 — 20.6
OPD 60 70 50 60 — 45 — 20
with SCR Reheat and Humidifier
3
FLA 56.8 74.4 47.8 62.5 — 47.3 — 24.0
WSA 67.1 89.1 56.7 75.1 — 56.3 — 28.6
OPD 70 90 60 80 — 60 — 30
* Specify disconnect or no disconnect
Notes:
1. Belt drive data includes externally mounted high static blower box, powered from evaporator unit.
2. Use MM*24E and MM*36E for MM*24K & MM*36K, respectively, except with SCR reheat.
3. SCR Reheat not available with MM*24K or MM*36K.
Table 9.12 Electrical data, 60Hz water/glycol-cooled systems using single-point power kit,
evaporator with belt-drive blowers and indoor condensing unit (continued)
220 - 1 Ph - 50Hz 380/415 - 3 Ph - 50Hz
Base Evaporator Model Number MM*35E MM*35E
Condensing Unit Model Number MC*37W MC*37W
Cooling Only
FLA 19.9 7.8
with Electric Reheat
FLA 44.9 17.5
with SCR Reheat
2
FLA 61.6 21.7
with Humidifier
Table 9.13 Electrical data, 50Hz water/glycol-cooled
systems using single-point power kit, evaporator with
direct-drive blowers and indoor condensing unit
