Vertiv Liebert Trinergy Cube User Manual

Figure 2.3 Customer Connection Locations in All Models
Slot 1 for Native LIFE™ Communication Cards
Slot 2 and 3 for Liebert® IntelliSlot® Communication Cards
AP90-XP11 (1-12) Selectable Inputs Dry Contacts (Up to 8 Form A/B or 4 Form C Inputs)
AP90-XP12 (1-18) Selectable Outputs Dry Contacts (6 Form C outputs)
AP83-TB11 - (1-12) Selectable Inputs Dry Contacts (Up to 8 Form A/B or 4 Form C Inputs)
AP83-TB12_1 - (1-9) Selectable Outputs Dry Contacts (6 Form C Outputs)
AP83-TB12_2 - (10-18) Selectable Outputs Dry Contacts (6 Form C Outputs)
Table 2.1 Connection Interfaces
2 Introduction
7
