5 SPECIFICATIONS
UPS Rating at 95°F (35°C), kVA 400 - 1600
UPS Rating at 104°F (40°C), kVA 375 - 1500
Output Active Power at 95°F (35°C), kW 400 - 1600
Output Active Power at 104°F (40°C), kW 375 - 1500
Input AC Parameters
Input Voltage to Rectifier/Bypass, VAC 480, 3-Phase, 3-Wire
Permissible Input Voltage Range +10%, -10%
Input Frequency, Hz 60± 5
Input Power Factor ≥ 0.99
Input Current Distortion (THDi) at Nominal Voltage at Full Load,
%
≤ 3.0
Power Walk-In (seconds) 1 to 90 (Selectable in 1 Second Increments)
Internal Back-Feed Protection Yes
Input Connection Single or dual feed
Short-Circuit Withstand Rating (kA) 100
Battery and DC Parameters
Battery Type Vertiv HPL, Lithium ion, VRLA (Valve Regulated Lead Acid), VLA (Vented Lead Acid)
Nominal Battery Bus , VDC / Battery Float Voltage, VDC 480 / 540
DC Ripple at Float Voltage < 1.0% (RMS value) < 3.4% Vpp
Temperature Compensated Battery Charging Standard with Vertiv™ VRLA Battery Cabinets
Output Parameters
Load Power Factor Supported (Without Derating) 0.7 Leading to 0.4 Lagging
Output Voltage, VAC 480, 3-Phase, 3-Wire
Output Voltage Regulation (%) / Output Voltage Regulation (50%
Unbalanced Load) (%)
< 1.0 (3-phase RMS average) / < 2.0 (3-phase RMS average)
Output Frequency, Hz 60 ± 0.1%
Output THD at Nominal Voltage (Linear Load), % ≤ 1.5 (RMS Value)
Output THD at Nominal Voltage Including a 100kVA Non-Linear
Load per IEC 62040-3, %
≤ 5.0 (RMS Value)
Translent Recovery 100% Load Step / 50% Load Step / Loss
of/Return to AC Input Power
±4% / ±2% / ±2% (RMS average for one cycle)
Voltage Displacement (Balance Loads) / Voltage Displacement
(50% Balance Loads)
120 deg ±1 deg / 120 deg ±2 deg
Overload at Nominal Voltage and 77°F (25°C)
110% continuously; 125% for 10 minutes; 150% for 60 seconds; 200% for 200
milliseconds
Table 5.1 Trinergy™ Cube Specifications and Standards
