Component Type Text Display ID Description
Rectifier Status Rectifier Warning 02-071 Set when at least one customer warning is active (not yet defined).
Rectifier Status
Rectifier Non-
Blocking Fault
02-072 Set when a customer non-blocking fault in stage is set (not yet defined).
Rectifier Status
Rectifier Stopped -
Fault
02-092
Rectifier Status Rectifier Inhibited 02-093 Set when the rectifier pulse is inhibited due to DC overvoltage.
Rectifier Status
Rectifier mains is out
of tolerance
12-005 Mains failure notification without any delay.
Appendix B: Trinergy™ Cube Alarm Messages
Component Type Text Display ID Description
Battery Alarm
Battery under
voltage
24-012
The battery voltage is under the shutdown voltage defined by 5 points of
P1513 Shutdown Voltage Table. This warning causes the inverter to stop.
This warning will be kept as long as the battery voltage is lower than the
Inverter Restart Threshold.
Battery Alarm
High battery
temperature
24-015
RBM battery temperature user alarm
(Temp. P1533.1 [0°C] < T <P1533.2 [38°C.])
Battery Alarm
Battery temperature
out of range
24-016
RBM battery temperature is out of range -10°C<T<P1533.1 or 1533.2 < T <
40°.
Battery Alarm
Temperature Probe
Broken
24-017
RBM temperature probe is not responding (Temp.T<10°C or T > 50°C or
RBM Sensor Status [bit3-2] = 11.
Battery Alarm
Battery Switch Wiring
Fault
24-056
Core only: Set when the RBM option is installed with Form C wiring and
related cubicle breaker wiring fails.
Battery Alarm
Cubicle Battery
Switch Open
24-063
Core and Monolithic.
CORE: set when an RBM option is installed.
Monolithic: set when IO Function 18 is enabled.
Battery Alarm
Battery Is Not
Connected
24-064 Battery is not connected - warning.
Battery Alarm
Imminent End Of
Autonomy - Volt
24-066
Set if P1590 = 2 or 3. The battery voltage is lower than the threshold
defined by 5 points of P1513 Shutdown Voltage Table + P 1591 Delta
shutdown imminent.
Battery Alarm
Imminent End Of
Autonomy - Time
24-067
Set if P1590 = 1 or 3. The autonomy is below the defined threshold P1117
Battery stored energy time limit.
Battery Alarm BCB Breaker Open 24-068 Enabled by Input Function 21 BCB. Battery Circuit Breaker (BCB) is open.
Battery Alarm
Battery Breaker
Open
24-072 One or more BIB boards report an open breaker.
Bypass Alarm
Bypass Input Switch
Open
21-012 Bypass input switch is open.
Bypass Alarm Bypass mains failure 21-013 Warning set after delay defined by P 110.
Vertiv™ | Liebert® Trinergy Cube™ Operation and Maintenance Guide
48
