Figure 3.6 Attached battery cabinet busbar connections toNXL input/output cabinet
ITEM DESCRIPTION
1 Standard input/output cabinet
2 Positive DCbusbar
3 Negative DCbusbar
The Liebert NXL is available in multiple configurations (single-module, multi-module, 1+N and N+1). For configurations
without an input/output cabinet, refer to the submittals that shipped with the UPS.
