4 SPECIFICATIONS
Battery Cabinet Parameters
Values
Top-Terminal Cabinet Front-Terminal Cabinet
Battery Type VRLA (Valve Regulated Lead-Acid)
Nominal Battery Bus, VDC 480V
Battery Float Voltage, VDC 540V
Minimum EOD Voltage, VDC 384V (for VRLA / Flooded Lead-Acid)
Physical Parameters and Standards
Width, in. (mm)
1
Standard Width: 56.5 (1435)
Reduced Width: 48.3 (1227)
63.0 (1600)
Depth, in. (mm)
2
33.5 (850) 33.5 (850)
Height, in. (mm) 76.8 (1950) 76.8 (1950)
Weight, lb (kg) approx. See Table 4.4 on page32
Standard Color Black (ZP-7021)
Front Door Opening (for serviceability) More than 180°
Degree of Protection for UPS Enclosure IP 20 (with and without front door open)
Minimum Clearance, Top 24" (610mm)
Minimum Clearance, Back 0in.
Minimum Clearance, Sides 0in.
Cable Entrance Top or Bottom
Standards and Conformities
UL 1778; CSA 22.2 107.3
FCC Part 15, Class A; ISTA Procedure 1H; WEEE;
IBC 2012/CBC 2010
Environmental Parameters
Storage Temperature Range
-4°F to 104°F (-20°C to 40°C)
3
74°F to 80°F (23-27°C) for optimal battery life
Table 4.1 Liebert Battery Cabinet Specifications
4 Specifications
29
