Battery Manufacturer Battery Code Battery Model # Cabinet Weight, lb(kg) Breaker Frame Size Torque Value, in.-lb(Nm)
EnerSys 4K 16HX925F-FR 9100 (4128)
Liebert® NX™ 225-600
225kW 600AT/600AF
250kW 700AT/1200AF
300kW 800AT/1200AF
400-600kW: 900AT/1200AF
100 (11.3)
EnerSys 4K 16HX925F-FR 9100 (4128)
Liebert® NXL™
225kW 700AT/1200AF
270kW 800AT/1200AF
360-1100kW: 900AT/1200AF
100 (11.3)
East Penn QA HR3000 3565 (1617) 400AT/600AF 65 (7.3)
East Penn TA HR3500 3965 (1798) 450AT/600AF 65 (7.3)
East Penn VA HR4000 4375 (1984) 500AT/600AF 65 (7.3)
East Penn WA 31HR5000 5095 (2311) 500AT/600AF 65 (7.3)
East Penn YA HR5500 5455 (2474) 600AT/600AF 65 (7.3)
Table 4.4 Battery-cabinet Weight and Breaker Frame Size (continued)
Cable Size T&B Copper OneHole T&B Copper TwoHole T&B Aluminum OneHole T&B Aluminum TwoHole
#8AWG 54930BE 54850BE 60104-TB —
#6AWG 54905BE 256-30695-868 60109-TB —
#4AWG 54906BE 256-30695-733 60114-TB —
#2-3AWG 54942BE 54811BE 60120 —
#1AWG 54947BE 54857BE 60126 —
#1/0AWG 54950BE 256-30695-593 60132 —
#2/0AWG 54951BE 54862BE 60138 60238
#3/0AWG 54965BE 54864BE 60144 60244
#4/0AWG 54970BE 54866BE 60150 60250
250kcmil 54913BE 54868BE 60156 60256
300kcmil 54914BE 54870BE 60162 60262
350kcmil 54915BE 54872BE 60165 60267
400kcmil 54916BE 54874BE 60168 60269
500kcmil 54918BE 54876BE 60171 60273
600kcmil 54920BE 54878BE 60176 60275
750kcmil 54922BE 54880BE 60178 60277
Table 4.5 Recommended Lug Sizes
