Vertiv™ NetSure™ 7100 Series -48 VDC Power System User Manual
17
3. Place the module into an unoccupied mounting position without sliding it in completely. Rectifiers modules can be installed
in any mounting position of each module mounting assembly. Converters modules can be installed in any of the three far
right mounting positions of each module mounting assembly (as viewed from the front). See Figure 4.3.
4. Loosen the captive screw on the module’s handle. Pull the handle down out from the module’s front panel (this will also
retract the latch mechanism). See Figure 4.3.
5. Push the module completely into the shelf.
6. Push the handle up into the module’s front panel. This will lock the module securely to the shelf. Tighten the captive screw
on the handle.
7. Repeat the above steps for each module being installed in the system.
8. After the modules are physically installed in the module mounting assembly(s), they are ready for operation immediately after
power is supplied to them.
NOTE! It is recommended that the current limit point be checked whenever a rectifier is added to or removed from the
power system. Refer “
Checking the Controller’s Current Limit Point after Adding or Removing a Rectifier Module or Converter
Module” on page 44.
NOTE! The rectifier or converter being added is assigned by the controller the lowest available identification number. If
desired, you can change the identification number. Refer to the NCU Instructions (UM1M830BNA) for a procedure.
