Vertiv™ NetSure™ 7100 Series -48 VDC Power System User Manual
77
Figure 5.15 SM-DU Circuit Card Replacement (Supplemental Bays Only)
SM-DU
Supplemental
Bay Addressing
8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1
SM-DU Circuit Card
S 1S2S3
JP1
JP2
JP3
J5
J4J4A
J3
J1
J2
Power
CANRS485
R
S
4
8
5
RS232
ON
OFF
Green Indicator (Operation)
Yellow Indicator (Alarm)
Red Indicator (Alarm)
