Vertiv™ NetSure™ 7100 Series -48 VDC Power System User Manual
80
Figure 5.17 EIB (Controller Extended Interface Board) Connector Locations
Optional EIB Interface Board
(Top View)
Optional EIB Interface Board Assembly
J3 J4J2
J9J8J7J6J5
J5-J9
Wire Size Capacity: 16-26 AWG.
Recommended Torque: 2.2 in-lbs.
SW1
1
2
ON
OFF
RLY02RLY05
RLY01
RLY04
RLY03
