Vertiv™ NetSure™ 7100 Series -48 VDC Power System User Manual

Figure 5.19 IB4 (NCU Controller Second Ethernet Port Board) Replacement

List 21 Distribution Cabinet

(othe rs similar)

Installed View

Componen ts removed in

illustration for clarity.

IB4 Board

Screws to secure IB4

boa rd to stando ffs located

at top of distribution cabine t.

IB4 Boa rd

Cover

Screws to secure IB4

boa rd cover to top of

distribu tion cabine t.

10M Ethernet

Port (RJ-45)

USB-A Port

(not used)

USB-B Port

(Factory Connected)
