Vertiv VRC1 Series Installer/User Guide

1.2.1 Cooling Capacity
Table 1.4 below, lists the net-sensible cooling capacity for various evaporator and condenser-air inlet
temperatures.
Condenser Air temperature, °F
85 95 104
Evaporator Air Temperature
into unit, °F
85 3.2 2.8 2.4
95 3.7 3.4 3.0
104 4.0 3.9 3.2
Table 1.4 Net Sensible (IT) Cooling Capacity, kW
NOTE: The addition of heat-rejection duct work may reduce cooling capacity.
Vertiv™ | VRC Installer/User Guide
6
