Vertiv VRC1 Series Installer/User Guide

1 VERTIV™ VRC
The VRC is a compact, integrated, rack-mounted cooling unit for use in a 19-in. EIA server rack.
Specifically designed for the cooling demand of the equipment mounted inside the rack, the VRC features
high reliability, high sensible-heat ratio and high air flow.
Figure 1.1 VRC Rack-mounted Cooling Unit
Item Description
1 Front view of VRC
2 Rear view of VRC
Installed at the bottom of the cabinet, the VRC provides air flow as shown in Figure 1.2 on the next page.
Hot return air enters from the rear of the cabinet, and conditioned cold air is supplied at the front of the
unit directly in front of the rack-mounted equipment..
Cooling capacity varies from 30% to 100%, approximately 0.9kW to 3.5kW to accommodate partial or
variable cooling loads.
1 Vertiv™ VRC
3
