Vertiv VRC1 Series Installer/User Guide

Figure 6.1 Evaporator Filter
Item Description
1 Cross-head screw, M4x10
2 Front bracket
3 Filter
4 Top bracket
To clean the condenser filter:
1. Turn off the unit.
2. Remove the filter bracket by removing the two screws at the top of the bracket, see Figure 6.2
on the facing page.
3. Remove the filter from the bracket and clean the filter with water or compressed air.
4. Replace the filter in the bracket.
5. Re-install the bracket on the unit using the two screws.
Vertiv™ | VRC Installer/User Guide
30
