DGT / DGT60 / DGTQ / DGTP
18
COM2 The communication between the indicator and the PC takes place through the COM1 serial port
while the transmission of the data to the printer takes place through the COM2 serial port or does not
take place for the DGTQPB and DGTPPB.
(!) COM2
 CoM.Prn PRINTER SERIAL
o PrModE TRANSMISSION UPON THE PRINTER SERIAL
 Pr- no transmission disabled.
 tpr enables the printing with ASCII printer (for example DP190 or TPR).
 LP542P enables to print with labelling machine LP542S
 ALL.Std continuous transmission with standard string.
 ALL.Eht continuous transmission with extended string (or multiscale string in the TRANSM mode).
 PrPC.St transmission of the standard string upon the pressing of the PRINT key.
 PrPC.EX transmission of the extended string upon the pressing of the PRINT key.
NOTE: if the "TOTALIZER" mode (horizontal or vertical) is active, the transmission through
the key is carried out by pressing the MODE key.
The transmission of the standard or extended string upon the pressing of the PRINT key is
confirmed by "trAnSM" on the display.
 rEPE.6 transmission to 6-digit remote display.
 rEPE.4 transmission to 4 digit remote display.
(!) Pr-no
Notes:
- By selecting the REPE.6 protocol the serial output is automatically set at 4800, N-8-1. In any case it’s
possible to set it differently.
- In the MASTER/SLAVE functioning mode (see section 8.4 MULTISCALE REPEATER (MAStr),USER
MAN. REF) for the printer port the transmission modes are enabled to the printer and the
"rEPE.6/rEPE4" transmission mode.
- If one wants to use the LP542S printer, select the LP542P item.
For the protocol and transmission mode specifications, see section 6.4 "SERIAL PORT TRANSMISSION
MODES" and 6.6 "TRANSMISSION PROTOCOLS".
o bAud.Pr SET BAUD RATE
By pressing the PRINT key one accesses the selection of the data transmission speed (measured in Baud
= bit/second). The possible values are:
1200, 2400, 4800, 9600, 19200, 38400, 57600,115200.
(!) 9600
o bit.Pr SET PARITY, WORD, STOP BIT
By pressing the PRINT key one accesses the selection of the available values: n-8-1, n-8-2, n-7-2, E-7-1,
E-7-2.
(!) n-8-1
o PWr.Prn SETTING PRINTER MANAGEMENT
In this step one programmes the management of a possible connected printer:
PWr.EXt with instrument on, printer managed.
Ext.oFF printer managed; the start-up characters are sent to the printer, because the printer is
considered to be configured in the energy saving mode.
(!) PWr.EXt
