DGT / DGT60 / DGTQ / DGTP
19
o Prn.CtS RTS/CTS STATUS CONFIGURATION (§)
On the printer serial line the indicator has a CTS input (Clear To Send). A device (like a printer) that is slow
in processing the data received, can interrupt the transmission temporarily using this signal.
• noCtS no signal
• CtSL CTS active low (for LP542, TPR, DP24 printers)
• CtSh CTS active high (for DP190 printers)
• EmuCtS Emulation of the CTS signal: one is asked to enter the number of characters (nChrS), in 3
digits, which will be transmitted to the printer upon each transmission; then one needs to enter the
waiting time in milliseconds (tiME), in 4 digits, between a transmission and another.
The TIME OUT of a printout is a minute, in other words, after a minute that the printout is blocked, it is
cancelled.
(!) noCtS
(§) The parameter is not displayed unless "tPr" or "LP542P" has been selected in the "PrModE" step.
o PrConF CONFIGURATION OF THE PRINTOUTS (§)
See the 8 "Print Programming" section for the description of all the menu’s parameters.
(§) The parameter is not displayed unless "tPr" or "LP542P" has been selected in the "PrModE" step.
 CoM.PC PC SERIAL
o PCModE TRANSMISSION ON THE PC SERIAL
(§) If one has selected the rEPE functioning mode in the FModE >> FunCt step, only the "rEPE.6" and
"W.rEPE" parameters are displayed.
 ondE transmission on external command PC (given from PC or PLC, for example)
 rEPE.4 transmission to 4 digit remote display.
 rEPE.6 transmission to 6 digit remote display / Reception of the “rEPE.6” string.
 Prin.St. transmission of standard string when the PRINT key is pressed.
 Prin.EX transmission of extended string when the PRINT key is pressed.
NOTE: if the "TOTALIZER" mode (horizontal or vertical) is active, the transmission through
the key is carried out by pressing the MODE key.
The transmission of the standard or extended string upon the pressing of the PRINT key is
confirmed by "trAnSM" on the display.
 485 transmission with 485 protocol, by confirming with PRINT, one is required to enter the
machine code (the message "Ad485" appears for an instant): enter a value between 0 and
98.
 ModbuS Transmission with the MODBUS protocol
 ProFib Transmission with the PROFIBUS protocol
 ALL.Std continuous transmission with standard string.
 ALL.EXt continuous transmission with extended string (or multiscale string in the TRANSM mode).
 StAb.St transmission with each weigh with standard string.
 StAb.EX transmission with each weigh with extended string (or multiscale string in the TRANSM
mode).
 W.rEPE (§) Reception of string from remote scale. (§) The parameter is displayed only if one has
selected the rEPE functioning mode in the FModE >> Func step.
By confirming with PRINT one is requested to set the following parameters for the
management of the remote scale:
tErM REMOTE SCALE TERMINATOR
In this step one enters the decimal ASCII code (up to 2 characters) of the terminator characters of the
weight string (I.E. 13 for CR or 10 for LF).
(!) 00
