DGT / DGT60 / DGTQ / DGTP
20
WEi.PoS REMOTE SCALE WEIGHT POSITION
In this step one sets the position of the first character of the weight value, in the string transmitted by the
remote scale, knowing that the first character on the left of the string has the 00 position.
A possible character sign is also part of the weight value.
For example, if the received string is spppppppuu + CR + LF:
Received string s p p p p p p p u u CR LF
Position of the
character 00 01 02 03 04 05 06 07 08 09 10 11
Therefore one should set the 00 value.
It is possible to set up to 2 characters (from 0 to 39).
(!) 00
WEi.LEn LENGTH OF THE WEIGHT DATA STRING
In this step one enters the number of digits (from 1 to 39) which make up the weight value, including the
sign and the non significant digits (for example, if the transmitted string spppppppuu + CR + LF, in
which s is the weight sign, ppppppp is the weight value, uu is the unit of measure, one should set the
08 value).
Str.LEn LENGTH OF THE COMPLETE STRING
In this step one enters the number of digits (from 0 to 39) which make up the entire string transmitted
from the serial line scale, less the terminator character (for example, if the transmitted string is
spppppppuu + CR + LF, in which s is the weight sign, ppppppp is the weight value, uu is the unit of
measure, one should set the value 11).
(!) 01
dECi. REMOTE SCALE DIVISIONS
Enter the number of scale’s decimals (from 0 to 5).
(!) 0
The two following parameters allow to generate the weight stability communicated by the remote scale
and allow to manage the stability LEDs on the indicator:
StAb NUMBER OF READINGS PER STABILITY
Enter the number of consecutive readings which the indicator must consider to obtain the stability (2
characters, from 0 to 20).
(!) 03
StA.int WEIGHT DIFFERENCE PER STABILITY
Enter the maximum value (2 characters, from 0 to 20) of the difference between the weights of the
consecutive readings, set in the previous step.
If the weight difference between the readings is equal or less than the set value, the weight is
considered to be stable (stability LED off), otherwise the weight is considered to be unstable (stability
LED on).
(!) 02
 Pr1577 Reception of the “rEPE.6” string. (§) The parameter is displayed only if one has selected
the rEPE functioning mode in the FModE >> FunCt step.
(!) ondE
NOTES:
-
If the functioning mode selected in the FModE >> FunCt step is different than rEPE, by selecting the
REPE6 or REPE4 protocol the serial output is automatically set at 4800, N-8-1.
By selecting the Pr1577 protocol the serial output is automatically set at 4800, E-7-1.
In any case it’s possible to set it differently.
